Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)

Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)

$116.70
$116.70
Ga direct naar de productinformatie
Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
  • Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)
Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)

Magewell USB Capture SDI Plus– 1-Channel SDI to USB 3.1 Audio/Video Capture with Loop-Through, Analog Line I/O, Up to 2K / 120fps (32050)

$116.70
$116.70
The Pro Plug and Play Solution
Up to 2K resolutions at up to 120 FPS
Compatible with all streaming apps
Offload your video processing
Includes Software: Capture Express

Magewell USB SDI Capture Devices

USB Capture SDI Plus

USB Capture SDI Gen 2

USB Capture SDI 4K Plus

USB Capture SDI 4K Pro
Customer Reviews
4.6 out of 5 stars 68
4.6 out of 5 stars 100
4.6 out of 5 stars 20
—
Price
$389.00 $319.00 $545.00 $635.00
SKU
32050 32070 32100 32160
Video Input Interface
3G-SDI 3G-SDI 6G-SDI 12G-SDI
Input Signal Up To
2048x1060 60fps 4:2:2 2048x1060 60fps 4:2:2 4kp30 4:2:2 4Kp60 4:2:2
Capture Signal Up To
1080p60 4:4:4 1080p60 4:4:4 4kp30 4:2:0 4Kp60 4:2:2
Loop-Through Output
✔ ✘ ✔ ✔
Audio
Embedded, 3.5mm In/Out Embedded Only Embedded, 3.5mm In/Out Embedded, 3.5mm In/Out
  • High-Quality 2K SDI Capture – Accepts SD/HD/3G/2K SDI input (up to 2048×1080 60fps) and captures up to 120 fps for smooth, detailed video.
  • SDI Loop-Through for Monitoring – BNC loop-through lets you route the signal to an external monitor while capturing without latency.
  • Flexible Audio Handling – De-embed SDI embedded audio or feed in analog line audio (3.5 mm). Output via analog line out for monitoring.
  • FPGA-Based Video Processing – Onboard cropping, scaling, de-interlacing, color format conversion and flip/mirror reduce load on your computer.
  • Plug-and-Play USB 3.1 – No drivers needed; works out-of-the-box on Windows, macOS, Linux, and Chrome OS. Backward compatible with USB 2.0 (at lower performance).
  • Reliable for 24/7 Use – Designed for continuous operation with robust thermal design, status LEDs, and backed by a 3-year warranty.
  • Control & Updates via Utility – Use Magewell’s utility software to configure EDID, video settings, firmware updates, and diagnostics.
› See more product details
